商品詳細介紹Product Introduction
WIRE RANGE
AWG / mm2 |
ITEM NO. |
UL |
DIMENSION inch(mm) |
| B |
L |
F |
E |
d1 |
t |
NEMA TAB |
22~16 AWG
0.5~1.5 mm2 |
M1-6.4HC
|
 |
.250(6.35) |
1.457(37.0) |
.307(7.8) |
1.043(26.5) |
.067(1.7) |
.016(0.4) |
.032*.250
(0.8*6.4) |
16~14 AWG
1.5~2.5 mm2 |
M2-6.4HC
|
|
.250(6.35) |
1.457(37.0) |
.307(7.8) |
1.043(26.5) |
.091(2.3) |
.016(0.4) |
.032*.250
(0.8*6.4) |
12~10 AWG
4~6 mm2 |
M5-6.4HC
|
|
.250(6.35) |
1.457(37.0) |
.307(7.8) |
1.043(26.5) |
.134(3.4) |
.016(0.4) |
.032*.250
(0.8*6.4) |
商品備註說明Product Remark
MAXIMUM ELECTRICAL RATING :
300 VOLTS
SHRINK TEMP : 150
OPERATING TEMP : - 10
TERMINAL MATERIAL : BRASS
PLATING : ELECTRO TIN PLATED
SLEEVE : C TYPE SLEEVE
INSULATION MATERIAL : HEAT SHRINKABLE TUBE
